D-SUB VGA PCB Mount Right Angle Connector, Compact & Reliable D-Subminiature Connector
Pins at a right angle for PCB mounting.
Nickel-plated terminals.
Good quality.
Choose Quantity
Connector Type | DB-9|15|25|37 |
|---|---|
Connector | Male |
Voltage Rating (V) | 250V AC |
Current Rating (A) | 5 |
Insulation Resistance (MOhm) | 1000 |
Contact Resistance | 20mΩ |
Operating Temperature (°C) | -55 to 125 |
Material: | Metal |
DB Right Angle Connector is the most common type of electrical connector. DB connector is part of the D-sub miniature (D-sub) connector plug and socket family for computer and communication devices.The terminals of this connector are bent at a right angle.
DB connectors are designed to work with the EIA/TIA 232 serial interface standard, which determined the function of all nine pins as a standard so that multiple companies could design them into their products. DB connectors were commonly used for serial peripheral devices like keyboards, mice, joysticks, etc. Also, they are used in DB cable assemblies for data connectivity.
Applications:
Network ports.
Computer video output.
Game controller ports.
Linear and rotary encoders in industries.
